规格参数
|
Processor System |
CPU |
Intel ® Haswell1.4GHz/1.6GHz Duo Core CPU |
|
Chipset |
Intel ® Haswell | |
| BIOS |
SPI BIOS |
|
|
RAM |
Architecture |
DDR3 MAX 1666 MT/s |
|
Capacity |
MAX 16GB |
|
|
Socket |
SODIMM |
|
|
Display |
Graphic Controller |
Intel® HD4000 Graphic media accelerator |
|
DVI |
DVI-I port | |
| Max. resolution: 4096 * 2304 | ||
|
HDMI |
HDMI 1.4 |
|
|
Max. resolution: 4096 * 2304 |
||
|
Display Port |
DISPLAY PORT++ 1.2, support DP Dangle | |
|
Max. resolution: 3200 * 2000 |
||
|
Multiplex Display |
HDMI+DP+DVI Synchronous or asynchronous display |
|
| LAN |
Controller |
LAN 1: Intel®I210 GbE |
|
LAN 2: Intel®I210 GbE |
||
| Audio |
Controller |
Realtek HD ALC662 audio decoder(Right&left Channel + Mic) |
|
Super I/O |
Controller |
ITE8782, support 4*COM |
|
H/W Monitor |
Watch Dog Timer |
0-255 sec., provide watch dog routine |
|
Thermal |
Fanless, Aluminum passive heatsink |
|
| TPM |
Controller |
N/A |
| I/O |
USB |
6*USB (2*USB 3.0 PORT + 4*USB2.0 / 1.1) |
|
Serial Port |
Com1: 9-line RS232,RS232/485 (Optional),TX/RX signal, |
|
|
support 4000Vsurge protection |
||
|
Com2-4: 3-line RS232,TX/RX signal, support 4000V surge protection |
||
|
GPIO |
8bits, support routine, freely define I/O,3.3V@24mA level |
|
|
Expansion Bus |
SMBUS |
Inter integration |
|
Mini-PCIe |
1* Half-size Mini-PCIe socket, support PCIe & USB devices |
|
|
1* Full-size Mini-PCIe socket, support USB 3G/4G communication Module |
||
|
UIM Scoket |
3G UIM slot |
|
|
Storage |
SATA |
1* standard 7Pin SATA-III & power port, max. transmission rate:3Gb/s |
|
Laptop SATA |
7+15Pin |
|
|
M-SATA |
1*Half-size m-SATAII scoket, max. transmission rate:3Gb/s |
|
|
Power |
Power Type |
DC9-19V extended voltage dynamic input, support reverse |
|
power protection, 3 Pin 5.08mm phoenix port. |
||
|
Power Consumption |
Typical Power: 15W |
|
|
Indicator |
Status Indicator |
HDD LED |
|
POWER LED |
||
|
Environment |
Operating Temp. |
-20°C ~ 60°C With SSD; 0°C ~ 40°C With HDD |
|
Storage Temp. |
-40°C ~ 80°C |
|
|
Operating Humidity |
0% ~ 90% relative humidity, non-condensing |
|
|
Storage Humidity |
0% ~ 90% relative humidity, non-condensing |
|
|
Formfactor |
Dimensions |
210mm * 136mm * 35mm |
|
Weight |
|
|
|
Certificate |
FCC, CE, RoHS |
|
