规格参数
|
Processor System |
CPU |
Intel Processor D2550 CPU(1.86GHz) |
|
Chipset |
Intel @NM10 Express chipset | |
| Memory |
2xDDR3 1067MHz Single CH SO-DIMM up to 4GB |
|
|
HDD |
2xSerial ATA2 320Gb/s connectors |
|
|
PCI port |
1xPCI/1xMini PCI-E socket |
|
|
VGA port |
1xVGA port |
|
|
HDMI port |
1xHDMI port |
|
|
COM ports |
Defaultx2 COM | |
|
USB 2.0 ports |
Default x 4 USB | |
|
LAN |
2xRTL811EVL PCI-E Gigabit LAN |
|
|
Ethernet ports |
2x10/100Mbps Ethernet interface |
|
|
Audio |
MIC-IN,Line-out,Line-in | |
|
LCD Display |
Screen Size |
10.4" |
|
Max Resolution |
800x600 |
|
|
Support Color |
16.2M/262k colors |
|
|
Luminance(CD/㎡) |
230 |
|
|
Contrast Ratio |
500:1 |
|
|
Pixel Pitch (mm) |
0.264x0.264 | |
|
Viewing Angle(CR=10) |
140(H);120(V) |
|
|
Touch screen(optional) |
Type |
PCT Touchscreen(Multi Touch) |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Input Voltage |
AC 100～240V 4A 47～63Hz |
|
|
Output Rating |
10W(max) |
|
|
Ouput Voltage |
+5V 2A |
|
|
Relative Humidity |
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-20~70℃ |
|
|
Relative Humidity |
5(%RH)~90(%RH) |
