规格参数
|
Processor System |
CPU |
Intel ® Bay Trail-M N2930 SOC Processor 1.83G |
|
Memory |
DDR3L 1333MHz 4GB | |
| HDD |
Msata 32G |
|
|
DVI port |
1xDVI port |
|
|
COM ports |
4xCOM (optional) |
|
|
USB ports |
3xUSB2.0 (1xUSB 3.0) |
|
|
Ethernet ports |
2xRTL8111G PCI-E Gigabit LAN |
|
|
Audio |
1xLine-out port | |
|
LCD Display |
Display Size |
6.5" |
|
Active Display Area(mm) |
132.48(H)x99.36(V) |
|
|
Max Resolution |
640x480 |
|
|
Support Color |
16.2M/262K colors | |
| Brightness(cd/㎡) |
600 |
|
|
Contrast Ratio |
600:1 |
|
|
Pixel Pitch (mm) |
0.207(H)x0.207(V) |
|
|
Display Mode |
Normally White |
|
|
Viewing Angle (CR=10) |
160(H);140(V) |
|
|
Backlight |
LED | |
|
Touch screen(optional) |
Type |
Resistive Touchscreen |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Input Voltage |
DC 9-24V IN |
|
|
Output Rating |
20W(max) |
|
|
Dimension(VxHxT) |
208x158x53 |
|
|
Relative Humidity |
Operating Temperature |
-30~80℃ |
|
Storage Temperature |
-30~80℃ |
|
|
Relative Humidity |
5(%RH)~90(%RH) |
