    产品特点:

    支持嵌入式安装,VESA安装

    内置双风扇降温

    阳光下可视,防眩

    高亮度1000cd/㎡

    电阻触摸屏(5线,4线可选)

    强固型工业级结构设计

    应用行业:Kiosk自助查询机、AFC轨道交通等

    Contact Us
    规格参数
    型号           Model Name
    AMG-19OPXT02T1
    屏幕尺寸   Screen Size
    19"
    显示区域   Active Display Area (mm)
    376.32(H) x 301.06 (V)
    像素点       Pixel Pitch (mm)
    0.294(H) x 0.294 (V)
    显示模式   Display Mode
    Normally white
    分辨率       Display Resolution (pixel)
    1280x1024
    对比度       Contrast Ratio
    700:1
    颜色像素   Display Color
    16.2M colors
    触摸屏       Touch Screen(optional) Resistive touchscreen
    亮度           Brightness (CD/㎡)
    1000
    背光           Backlight
    CCFL/LED
    可视角度    Viewing Angles (CR =10)
    160 (H); 160 (V)
    响应时间    Response Time(Typ.Tr+Tf)
    6ms
    信号接口    Signal Connector
    VGA/DVI
    电源接口    Power Consumption
    DC 12V
    外观尺寸    Dimension(VxHxT)
    398.6x326.6x50
    工作温度    Operating Temperature
    0~50℃
    储存温度    Storage Temperature
    -20~60℃
    相对湿度    Relative Humidity
    5(%RH)~90(%RH)
