    产品特点:

    安卓系统

    电阻触摸屏

    支持嵌入式安装,VESA安装

    高清真彩色TFT显示屏

    全视角液晶显示屏幕

    HDMI/AV/TF CARD/LAN/USB 接口

    LED背光

    应用行业:数字标牌、娱乐、广告机、查询机广告显示屏等

    Contact Us
    规格参数
    型号           Model Name
    AMG-21IPMP01T1
    屏幕尺寸   Screen Size
    21.5"
    显示区域   Active Display Area (mm)
    476.64(H)x268.11(V)
    像素点       Pixel Pitch (mm)
    0.24825(H)x0.24825(V)
    显示模式   Display Mode
    Normally black
    分辨率       Display Resolution (pixel)
    1920x1080
    对比度       Contrast Ratio
    3000:1
    颜色像素   Display Color
    16.7M colors
    触摸屏    Touch Screnn(optional) Resistive touchscreen
    亮度           Brightness (CD/㎡)
    250
    背光           Backlight
    LED
    可视角度    Viewing Angles (CR =10)
    178 (H); 178 (V)
    响应时间    Response Time(Typ.Tr+Tf)
    25ms
    信号接口    Signal Connector
    HDMI/AV/TF CARD/LAN/USB/DC 2.0
    电源接口    Power Consumption
    DC 12V
    外观尺寸    Dimension(VxHxT)
    528X320X45
    工作温度    Operating Temperature
    0~50℃
    储存温度    Storage Temperature
    -20~60℃
    相对湿度    Relative Humidity
    5(%RH)~90(%RH)
