规格参数
|
Processor System |
CPU |
Intel ATOM N2600 Dual core 1.6GHz 32nm |
|
Memory |
RAM 2GB.DDR3 SO-DIMM | |
| HDD |
SATA DOM SM2244LT 4GB 2223 |
|
|
CD/DVD-ROM/RW |
NA |
|
|
PS/2 port |
NA |
|
|
VGA port |
1XVGA port |
|
|
COM ports |
Default x 1COM |
|
|
USB 2.0 ports |
Default 3xUSB 2.0 | |
|
Ethernet ports |
1x10/100/1000BASE-T Gigabit Ethernet | |
|
Audio |
Line-out,Mic-in |
|
|
LCD Display |
Display Size |
17" |
|
Active Display Area(mm) |
337.920(H)x270.336(V) | |
| Max Resolution |
1280x1024 |
|
|
Support Color |
16.7M |
|
|
Brightness(cd/㎡) |
250 |
|
|
Contrast Ratio |
1000:1 |
|
|
Pixel Pitch(mm) |
0.264(H)x0.264(V) |
|
|
Viewing Angle(CR=10) |
170(H);160(V) | |
|
Response Time(Typ.Tr+Tf) |
5ms |
|
|
Backlight |
LED |
|
|
Touch screen(optional) |
Type |
IR Touchscreen |
|
Power supply |
Use connector |
4pin USB2.0 |
|
Output Rating |
35W(max) |
|
|
Input Voltage |
+12V @5A; |
|
|
Dimension(VxHxT) |
425x364x60 |
|
|
Relative Humidity |
Operating Temperature |
0~50℃ |
|
Storage Temperature |
-20~60℃ |
|
|
Relative Humidity |
5(%RH)~90(%RH) |
