Specifications
|
Model Name |
AMG-07IPPC01T1-V1 |
|
Screen Size |
7" |
|
Active Display Area (mm) |
152.4 (H) x91.44 (V) |
|
Pixel Pitch (mm) |
0.1905 (H) x 0.1905 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800x480 |
|
Contrast Ratio |
500:1 |
|
Display Color |
16.2M/262K colors |
|
Brightness (CD/㎡) |
350 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
110(H)x130 (V) |
|
Response Time(Typ.Tr+Tf) |
30ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
234.6x173.4x47.8 |
|
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-20~70℃ |
|
Relative Humidity |
5(%RH)～90(%RH) |
