Specifications
|
Model Name |
AMG-10IPPC05G1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
216.96 (H) x 135.60 (V) |
|
Pixel Pitch (mm) |
0.0565 (H) x 0.1695 (V) |
|
Display Mode |
Normally Black |
|
Display Resolution (pixel) |
800x600 |
|
Contrast Ratio |
500:1 |
|
Display Color |
16.2M/262k colors |
|
Brightness (CD/㎡) |
1500 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
100 (H); 120 (V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
294.6x229x63.8 |
|
Operating Temperature |
-10~70℃ |
|
Storage Temperature |
-20~80℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
