Specifications
|
Model Name |
AMG-07OPSK83T1 |
|
Screen Size |
7" |
|
Active Display Area (mm) |
152.4 (H) x 91.44(V) |
|
Pixel Pitch (mm) |
0.0635 (H) x 0.1905 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
800x480 |
|
Contrast Ratio |
500:1 |
|
Display Color |
262k colors |
| Touchscree(optional) | Resistive touchscreen |
|
Brightness (CD/㎡) |
300 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
140 (H); 120 (V) |
|
Response Time(Typ.Tr+Tf) |
25ms |
|
Signal Connector |
VGA |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
215.5x126.1x31.2 |
|
Operating Temperature |
-20~70℃ |
|
Storage Temperature |
-30~80℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
