Specifications
|
Model Name |
AMG-10OPAS04N1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
210.4 (H) x 157.8 (V) |
|
Pixel Pitch (mm) |
0.0685(H) x 0.2055 (V) |
|
Display Mode |
Normally black |
|
Display Resolution (pixel) |
1024x768 |
|
Contrast Ratio |
500:1 |
|
Display Color |
16.2M colors |
|
Brightness (CD/㎡) |
500 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
176 (H); 176 (V) |
|
Response Time(Typ.Tr+Tf) |
25ms |
|
Signal Connector |
VGA/DVI/Audio/USB |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
251.9X202.7X30 |
|
Operating Temperature |
-30~70℃ |
|
Storage Temperature |
-30~80℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
