Specifications
|
Model Name |
AMG-10OPDS01T1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
210.4(H)x157.8(V) |
|
Pixel Pitch (mm) |
0.2055(H)x0.2055(V) |
|
Display Mode |
Normally black |
|
Display Resolution (pixel) |
1024x768 |
|
Contrast Ratio |
3000:1 |
|
Display Color |
16.2M/262k colors |
| Touch Screen(optional） | Resistive touchscreen |
|
Brightness (CD/㎡) |
400 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
178 (H); 178 (V) |
|
Response Time(Typ.Tr+Tf) |
30ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
260x213x38 |
|
Operating Temperature |
-30~80℃ |
|
Storage Temperature |
-30~80℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
