Specifications
|
Model Name |
AMG-55IPAS01T1 |
|
Screen Size |
54.6" |
|
Active Display Area (mm) |
1209.6(H)x680.4(V) |
|
Pixel Pitch (mm) |
0.21(H)x0.63(W) |
|
Display Mode |
Normally black |
|
Display Resolution (pixel) |
1920x1080 |
|
Contrast Ratio |
4000:1 |
|
Display Color |
1073.7M Colors |
| Touch Screnn(optional) |
Multi Touch/IR Touch |
|
Brightness (CD/㎡) |
450 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
178 (H); 178 (V) |
|
Response Time(Typ.Tr+Tf) |
5.5ms |
|
Signal Connector |
VGA/DVI/HDMI/BNC/Audio/S-Video/USB |
|
Power Consumption |
DC 24V |
|
Dimension(VxHxT) |
1340x810x80 |
|
Operating Temperature |
0~50℃ |
|
Storage Temperature |
-20~60℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
