Specifications
|
Model Name |
AMG-15OPDX01N6 |
|
Screen Size |
15" |
|
Active Display Area (mm) |
304.128(H) x228.096(V) |
|
Pixel Pitch (mm) |
0.294 (H) x 0.294 (V) |
|
Display Mode |
Normally white |
|
Display Resolution (pixel) |
1024X768 |
|
Contrast Ratio |
700:1 |
|
Display Color |
16.2M |
|
Brightness (CD/㎡) |
1000 |
|
Backlight |
LED |
|
Viewing Angles (CR =10) |
160 (H); 140 (V) |
|
Response Time(Typ.Tr+Tf) |
8ms |
|
Signal Connector |
VGA |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
338.9X265.9X45 |
|
Operating Temperature |
-30~85℃ |
|
Storage Temperature |
-30~85℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
