Specifications
|
Model Name |
AMG-10OPDR05N1 |
|
Screen Size |
10.4" |
|
Active Display Area (mm) |
211.2(H)x158.4(V) |
|
Pixel Pitch (mm) |
0.264(H)x0.264(V) |
|
Display Mode |
Normally black |
|
Display Resolution (pixel) |
800x600 |
|
Contrast Ratio |
500:1 |
|
Display Color |
16.2M/262k colors |
|
Brightness (CD/㎡) |
1500 |
|
Backlight |
CCFL/LED |
|
Viewing Angles (CR =10) |
100 (H); 120 (V) |
|
Response Time(Typ.Tr+Tf) |
35ms |
|
Signal Connector |
VGA/DVI |
|
Power Consumption |
DC 12V |
|
Dimension(VxHxT) |
204x210x48 |
|
Operating Temperature |
0~50℃ |
|
Storage Temperature |
-20~60℃ |
|
Relative Humidity |
5(%RH)~90(%RH) |
